  • SC96015AQFSR

  • SC96015AQFSR

    Descriptions
    The SC96015A is a highly integrated wireless power
    transmitter IC including a digital microcontroller and a
    power stage. The microcontroller includes a high
    performance 32-bit digital core, rich memory and
    peripherals. The power stage includes a full-bridge
    inverter, current sense amplifier, communication
    demodulator, linear regulator and protection circuit.
    The SC96015A integrates DP/DM and CC fast charge
    interface. To flexibly implement a QI Tx system, the
    SC96015A can request a high voltage from the
    adapter through CC1/CC2 or DP/DM interface. The
    SC96015A supports foreign object detection (FOD) by
    continuously monitoring the input voltage and input DC
    current. Besides, the SC96015A also supports input
    under-voltage lockout (UVLO), over-current protection
    (OCP) and over-temperature protection (OTP). These
    protections further enhance the reliability of the total
    wireless power transmitter system.
    The SC96015A is available in a compact 4 x 3 mm
    FCQFN package.

    • 0.00
      0.00
商品描述

Descriptions
The SC96015A is a highly integrated wireless power
transmitter IC including a digital microcontroller and a
power stage. The microcontroller includes a high
performance 32-bit digital core, rich memory and
peripherals. The power stage includes a full-bridge
inverter, current sense amplifier, communication
demodulator, linear regulator and protection circuit.
The SC96015A integrates DP/DM and CC fast charge
interface. To flexibly implement a QI Tx system, the
SC96015A can request a high voltage from the
adapter through CC1/CC2 or DP/DM interface. The
SC96015A supports foreign object detection (FOD) by
continuously monitoring the input voltage and input DC
current. Besides, the SC96015A also supports input
under-voltage lockout (UVLO), over-current protection
(OCP) and over-temperature protection (OTP). These
protections further enhance the reliability of the total
wireless power transmitter system.
The SC96015A is available in a compact 4 x 3 mm
FCQFN package.

Features

• Support WPC 15W fast charging

• 3.0V to 20V AVIN input voltage range

• 2.0V to 18V PVIN input voltage range

• Integrated low RDSON power FETs

• Integrated accurate current sense for FOD

• Integrated 32-bit Core/32K MTP /6K SRAM

• Voltage and current demodulation

• Deep low power mode Q detection

• Support DP/DM fast charger, USB Power Delivery

• UVLO/OVP/OCP/OTP


Applications

• WPC Compliant Wireless Power Transmitter

• Proprietary Wireless Chargers and Transmitter
