  • AS1190

    Features

    ●  3D (X, Y, Z) Magnetic Flux Switch
    ●  Omnipolar Operation, easy to use as output
    ●  Input Voltage Range : 1.65V to 5.5V
    ●  Micro-power consumption ideal for battery power applications: 1.3uA/1.8V
    ●  Very high sensitivity hall sensor
    ●  Low Power CMOS process technology
    ●  Chopper stabilization amplifier stage
    ●  High Magnetic Sensitivity
    ●  Good RF noise immunity
    ●  No need pull-up resistor
    ●  Small Solution Size
    ●  RoHS & Green Compliant

    ●  SOT23-3L & SIP-3L Packages

    ●  -40℃ to +85 ℃ Temperature Range


    • 0.00
      0.00
商品描述

Features

●  3D (X, Y, Z) Magnetic Flux Switch
●  Omnipolar Operation, easy to use as output
●  Input Voltage Range : 1.65V to 5.5V
●  Micro-power consumption ideal for battery power applications: 1.3uA/1.8V
●  Very high sensitivity hall sensor
●  Low Power CMOS process technology
●  Chopper stabilization amplifier stage
●  High Magnetic Sensitivity
●  Good RF noise immunity
●  No need pull-up resistor
●  Small Solution Size
●  RoHS & Green Compliant

●  SOT23-3L & SIP-3L Packages

●  -40℃ to +85 ℃ Temperature Range


Applications

●  Smart Meter

●  Cover switch
●  Contact-less switch
●  Air Cylinder, Antitheft window, Digital door lock
●  Water Purifier, Humidifier Bidet
●  Water Meter, Gas Meter, Watttmeter etc
●  Washing Machine,Rice Cooker, Refrigerator,Electronic Dictionary, Digital Camera etc
