  • AS1801A

  • AS1801A

    Features

    ●  Input Voltage Range : 2.2V to 5.0V
    ●  Micro-power consumption ideal for battery power applications
    ●  Omnipolar Operation, easy to use as output
    ●  Very high sensitivity hall sensor
    ●  Low Power CMOS process technology
    ●  Chopper stabilization amplifier stage
    ●  Magnetic Sensitivity (typical) BOP=±18Gauss, BRP=±10Gauss
    ●  Good RF noise immunity

    ●  No need pull-up resistor

    ●  Small Solution Size

    ●  RoHS & Green Compliant

    ●  DFN1216-4L, SOT553, TSOT23-3L & SIP-3L Packages

    ●  -40℃ to +85 ℃ Temperature Range


    • 0.00
      0.00
商品描述

Features

●  Input Voltage Range : 2.2V to 5.0V
●  Micro-power consumption ideal for battery power applications
●  Omnipolar Operation, easy to use as output
●  Very high sensitivity hall sensor
●  Low Power CMOS process technology
●  Chopper stabilization amplifier stage
●  Magnetic Sensitivity (typical) BOP=±18Gauss, BRP=±10Gauss
●  Good RF noise immunity

●  No need pull-up resistor

●  Small Solution Size

●  RoHS & Green Compliant

●  DFN1216-4L, SOT553, TSOT23-3L & SIP-3L Packages

●  -40℃ to +85 ℃ Temperature Range


Applications


●  Smart Meter

●  Cover switch

●  Contact-less switch
