    Features

    ●  Input Voltage Range : 2.2V to 5.5V

    ●  Bipolar Latch Operation, easy to use as output

    ●  Chopper stabilization amplifier stage
    ●  Magnetic Sensitivity (typical)BOP= ±25Gauss, BRP=±25Gauss
    ●  Good RF noise immunity
    ●  Integrated 10Kohms pull-up resistor
    ●  Small Solution Size
    ●  RoHS Compliant

    ●  DFN1014-4L,SOT23-3L and SIP-3L Packages

    ●  -40℃ to +125 ℃ Temperature Range


    • 0.00
      0.00
商品描述

Features

●  Input Voltage Range : 2.2V to 5.5V

●  Bipolar Latch Operation, easy to use as output

●  Chopper stabilization amplifier stage
●  Magnetic Sensitivity (typical)BOP= ±25Gauss, BRP=±25Gauss
●  Good RF noise immunity
●  Integrated 10Kohms pull-up resistor
●  Small Solution Size
●  RoHS Compliant

●  DFN1014-4L,SOT23-3L and SIP-3L Packages

●  -40℃ to +125 ℃ Temperature Range


Applications

●  Cover switch in Notebook, PC/PAD
●  Contact-less switch in consumer products
●  Solid State Switch
●  Handheld Wireless Handset Awake Switch
●  Lid close sensor for battery-powered devise
●  Magnet proximity sensor for reed switch replacement in low duty cycle applications
●  DV, DSC, and White Goods
