  • SC8101QFKR

  • SC8101QFKR

    SC8101 is a synchronous buck converter with a wide
    input voltage from 5V to 32V. The SC8101 regulates
    the output voltage at a fixed 5.1V or customized
    voltage by setting the divider resistor. It also provides
    high accurate output current limit. The converter
    enters Constant Current (CC) Mode in case the
    output reaches the setting current limit. The total
    output power can be programmed by a resistor,
    which makes it easy for constant power (CP) control.
    SC8101 integrates 45mΩ high side NMOS and
    30mΩ low side NMOS to achieve high efficiency.
    Besides, it provides low side gate driver (LSD) to
    drive external NMOS and works with build-in NMOS.
    SC8101 adopts programmable line drop
    compensation, programmable frequency setting with
    minimum external components, maximum functions
    can be achieved for user’s different applications.
    SC8101 also supports full protections including under
    voltage protection, over voltage protection, short
    current protection and auto-restart, over temperature
    protection.
    SC8101 adopts 19 pin QFN 3x3 package.    产品应用：

    车充

    提供快充功能的USB电源

    MFB电源供给

    工业应用


    • 0.00
      0.00
商品描述

SC8101 is a synchronous buck converter with a wide
input voltage from 5V to 32V. The SC8101 regulates
the output voltage at a fixed 5.1V or customized
voltage by setting the divider resistor. It also provides
high accurate output current limit. The converter
enters Constant Current (CC) Mode in case the
output reaches the setting current limit. The total
output power can be programmed by a resistor,
which makes it easy for constant power (CP) control.
SC8101 integrates 45mΩ high side NMOS and
30mΩ low side NMOS to achieve high efficiency.
Besides, it provides low side gate driver (LSD) to
drive external NMOS and works with build-in NMOS.
SC8101 adopts programmable line drop
compensation, programmable frequency setting with
minimum external components, maximum functions
can be achieved for user’s different applications.
SC8101 also supports full protections including under
voltage protection, over voltage protection, short
current protection and auto-restart, over temperature
protection.
SC8101 adopts 19 pin QFN 3x3 package.产品应用：

车充

提供快充功能的USB电源

MFB电源供给

工业应用


功能

●  4.4V to 32V输入电压范围●  最大输出容量5V/5A，集成内部MOSFETs

●  外部低端NMOS门驱动器●  几乎100%占空比运行

●  超低静态电流●  ±2%输出电压精度

●  ±4.5% 输出恒流精度●  可编程输出功率限制

●  可编程线路压降补偿●  PFM模式

●  固定150K开关频率或可由外部电阻器调节●  打嗝和自动重启

●  UVLO、IN/OUT OVP、OCP、OTP的全面保护

• Wide input operating voltage from 5V to 32V

• Max output capacity 5V/5A with internal MOSFETs

• External low side NMOS gate driver

• Almost 100% duty cycle operation

• Ultra-low quiescent current

• ±2% output voltage reference accuracy

• ±4.5% output current limit accuracy

• Programmable output power limit

• Programmable line drop compensation

• PFM mode

• Adjustable frequency 80kHz to 600kHz

• Hiccup and auto-restart

• Full protection of UVLO, IN/OUT-OVP, OCP, OTP

• Available in QFN-19 3x3 Package
